Analyze air pressure data from weather balloons

Image adapted from National Weather Service Forth Worth youtube channel

Weather Balloon Data

Earlier in Air Pressure Versus Height: Smartphone data we learned how to use smartphones to measure air pressure and how these devices are sensitive enough to detect the pressure change from even small changes in height. You can take measurements from your phone as you go up and down a stairwell. You can even attach your phone to a drone! This can be used to obtain pressure measurements as high as about 250 m above the ground, but how would we get pressure measurements from even higher than this? Answer: Weather balloons

How to obtain the data

  • Weather balloon data from across the world is freely available to analyze thanks to the National Oceanographic and Atmospheric Administration which has a public database at this link
  • It is important to figure out the code name for the weather station near you. For example, Wilmington, Ohio is USM00072426 and Amarillo, Texas is USM00072363. To find a weather station near you, look through this list of US station names with recent data. If you can’t find your city there you may be able to find it in the full list however note that for some cities the latest data available could be decades old which could be a problem because there may not be a height estimate for each pressure reading
  • Look for the data for your station on https://www.ncei.noaa.gov/data/integrated-global-radiosonde-archive/access/data-y2d/ You will find a zip file with the name of the station (for example: USM00072363-data-beg2025.txt.zip) Download that file and figure out a way to unzip or extract the file so that it looks like USM00072363-data.txt This file contains many ballon measurements at that location. You only need one measurement!
  • Here is what one measurement of pressure versus height looks like
#USM00072363 2025 01 01 00 2306  324 ncdc-nws ncdc-gts  352331 -1017091
21     0  89482B 1095    67B  420   120    92    15
20     7  89005  1139B   60B  362   138    40    29
20    20  88282  1204B   50B  387   129    59    26
20    28  87861  1244B   46B  397   125    60    26
20    45  86986  1325B   37B  418   117    83    26
20   105  85891  1428B   27B  440   110    65    16
20   121  85123  1500B   20B  457   104    70    19
10   123  85000  1512B   19B  460   103    70    20
20   203  82901  1714B    0B  504    90   180    29
20   205  82763  1727B   -1B  507    89   185    30
20   220  82001  1800B   -8B  527    84   179    14
20   245  80633  1934B  -22B  564    75   109    17
20   311  78968  2100B  -37B  610    64   136    31
20   325  78244  2172B  -43B  633    59   153    26
20   355  76772  2322B  -56B  668    52   179    28
20   514  72790  2738B  -71B  471    93   241    92
20   529  72108  2811B  -70B  449    99   250   111
20   543  71538  2873B  -71B  467    94   256   127
10   615  70000  3043B  -39B  425   108   273   150
20   621  69732  3074B  -39B  411   112   275   151
20   645  68604  3202B  -44B  360   127   279   174
20   705  67608  3317B  -47B  314   143   273   217
20   717  67080  3379B  -49B  306   146   274   225
20   745  65870  3522B  -56B  338   133   279   234
20   805  65015  3624B  -64B  355   127   279   216
20   824  64302  3710B  -70B  363   124   278   212
20   845  63357  3823B  -74B  344   129   276   210
20   917  61972  3997B  -81B  279   152   271   225
20   925  61636  4039B  -84B  283   150   270   230
20   953  60378  4200B  -92B  323   134   273   250
20   957  60206  4222B  -94B  326   133   274   251
20  1037  58461  4447B  -99B  150   216   281   299
20  1105  57281  4605B -106B  158   192   283   352
20  1125  56540  4705B -113B  124   214   283   377
20  1145  55859  4798B -121B  100   232   281   375
20  1225  54432  4995B -136B   72   260   284   387
20  1305  52862  5217B -146B   13   401   287   365
20  1318  52448  5276B -151B   12   402   286   364
............Many more lines of data!!!.............
20  9705   1100 30177B -500B   11   315    32    85
20  9725   1079 30305B -499B   11   316    25    96
20  9805   1038 30557B -494B   10   319    50    86
10  9843   1000 30804B -490B   10   321    43    83
20  9845    998 30817B -490B   10   321    42    82
20  9905    978 30948B -488B   10   321    51    81
20  9945    939 31214B -486B   10   321    34   103
20 10005    921 31344B -487B   11   320    28   101
20 10025    902 31481B -486B   10   320    30    91
20 10105    867 31744B -486B   10   320    49    88
20 10125    849 31882B -485B   11   319    36    82
20 10127    847 31894B -485B   11   319    35    83
20 10147    830 32030B -485B   11   319    22    91
20 10221    807 32249B -486B   10   320    20    93
30 -9999  -9999  1200 -9999 -9999 -9999    60    26
30 -9999  -9999  1500 -9999 -9999 -9999    65    15
30 -9999  -9999  1800 -9999 -9999 -9999   185    15
30 -9999  -9999  2100 -9999 -9999 -9999   135    36
30 -9999  -9999  2400 -9999 -9999 -9999   185    26
30 -9999  -9999  2700 -9999 -9999 -9999   235    82
30 -9999  -9999  3300 -9999 -9999 -9999   275   216
30 -9999  -9999  3600 -9999 -9999 -9999   280   221
30 -9999  -9999  3900 -9999 -9999 -9999   270   231
30 -9999  -9999  4200 -9999 -9999 -9999   275   247
30 -9999  -9999  4500 -9999 -9999 -9999   285   350
30 -9999  -9999  4800 -9999 -9999 -9999   280   376

We need to extract the third and fourth columns in order to plot the pressure versus height but this is a messy dataset that needs to be cleaned! For example, the fourth and fifth column includes the letter B next to the number which would be very confusing for any spreadsheet program to read in. If you are curious what these symbols mean it is explained in this file

Example data

Here are some examples of cleaned data where the extra symbols have been removed and all the lines that contain -9999 have been removed

What do to with the data

Earlier in Air Pressure Versus Height: Smartphone data we found that the air pressure decreases linearly with height, but we were only looking at data that was within 100 meters of the ground. Does the pressure versus height trendline continue to be linear above 100 meters? What mathematical function does it look like? Try plotting the pressure axis using a “log” scale.
